Plano Convex Cylindrical Lens
Plano Convex Cylindrical Lens
Plano convex cylindrical lenses are used in optics system ,laser system, scanner system and many other applications. Sunday is manufacturing circle plano convex cylindrical lens and square or rectangular plano convex cylindrical lens.
Parameter
| Structure | Plano Convex Cylindrical lens |
| Material | Optical glass, UVFS, Germanium, Silicon, CaF2, MgF2, ZnSe ZnS, Sapphire |
| Diameters Available | 2mm to 600mm |
| Diameter Tolerance | +0.00/-0.02mm or customer design |
| Surface Quality | 10-5 |
| Surface Irregularity | λ/10 @632.8nm or customer design |
| Thickness tolerance | +0/-0.02mm |
| Clear Aperture | >90% of Diameter |
| Chamfer | 0.05-0.5mmx45degree, according to customer’s needs. |
| Centeration | 3 arcmin |
| Coating | Single Mag2, Multiple Layers AR Coating A: 350-650nm B: 650-1050nm C: 1050-1585nm D: Customer Design |
